Migration from CefSharp to DotNetBrowser
This guide is for .NET developers who have existing CefSharp code and are considering migrating to DotNetBrowser.
Each section of this guide focuses on a specific CefSharp feature and explains how to replace it with DotNetBrowser.
This guide provides drop-in replacements for CefSharp calls and events, highlights key differences between DotNetBrowser and CefSharp, and includes helpful links to related documentation.
Installing dependencies
The easiest way to add DotNetBrowser to your project is through NuGet. Just install the package for your UI framework, and NuGet will take care of the rest. It will also download the core library and the Chromium files you need.
Ensure that you select the correct configuration from the beginning—match the architecture (x86, x64, or aarch64) and the UI framework (such as WPF or Avalonia).
Required packages:
DotNetBrowser.Wpf.x64
— WPF integration for Windows x64.- (Pulled transitively)
DotNetBrowser.Win-x64
— core API. - (Pulled transitively)
DotNetBrowser.Chromium.Win-x64
— bundled Chromium.
You can find the full list of NuGet packages for all supported UI frameworks and platforms in the installation guide.
If you’re not using NuGet, you can manually add DotNetBrowser to your project by referencing DLL files or VSIX packages.
Chromium engine
Initializing
In CefSharp, you start by initializing the underlying Chromium Embedded Framework (or simply CEF):
Cef.Initialize(new CefSettings());
In WPF and WinForms, CefSharp automatically calls this method. However, if you need custom settings, you call it manually first.
Note that this method must be called from the main thread and only once per process lifetime. Both limitations stem from CefSharp’s in-process architecture, which runs the Chromium engine in your .NET process and limits you to a single engine per process.
In DotNetBrowser, you also start by initializing the Chromium engine, but no limitations apply:
IEngine engine = EngineFactory.Create(RenderingMode.HardwareAccelerated);
DotNetBrowser has the out-of-process architecture and launches the Chromium engine in a separate process. That means you can create more than one engine per process, at any time, from any thread in your application.
We explore why you may need multiple engines in the Browser isolation section of this guide.
Shutting down
In CefSharp, you must shut down the Chromium engine when you don’t need it anymore, otherwise the application will hang.
Similarly, you must call this method in the main thread of the application. If you’re using WPF or WinForms, CefSharp will call this method for you.
In DotNetBrowser, you must always shut down the Chromium engine explicitly. You
may do it at any time, and from any thread. Failing to dispose of
the IEngine
leads to resource leaks but does not affect the .NET process:
Cef.Shutdown();
engine.Dispose();
Embedding the browser
WPF
Both CefSharp and DotNetBrowser provide WPF components that you can add directly to your XAML.
In fact, CefSharp provides two different components. If you need the off-screen
rendering, you’re using the WPF
implementation. If you need faster rendering,
you’re using the Wpf.HwndHost
implementation that re-parents the Chromium
window into your application.
DotNetBrowser provides a single component that can render the content in two
modes — roughly equivalent to those of CefSharp. They are
called HardwareAccelerated
and OffScreen
and you always choose the mode when
creating the IEngine
.
MainWindow.xaml:
<Window xmlns:wpf="clr-namespace:CefSharp.Wpf;assembly=CefSharp.Wpf"
x:Class="CefSharp.Wpf.MainWindow"
Title="CefSharp" Width="800" Height="600">
<Grid>
<wpf:ChromiumWebBrowser x:Name="Browser"
Address="https://www.teamdev.com" />
</Grid>
</Window>
<Window xmlns:wpf="clr-namespace:DotNetBrowser.Wpf;assembly=DotNetBrowser.Wpf"
x:Class="DotNetBrowser.Wpf.MainWindow"
Title="DotNetBrowser" Width="800" Height="600" Closed="Window_Closed">
<Grid>
<wpf:BrowserView Name="browserView" />
</Grid>
</Window>
MainWindow.xaml.cs:
public partial class MainWindow : Window
{
static MainWindow()
{
CefSettings settings = new CefSettings();
Cef.Initialize(settings);
}
public MainWindow()
{
InitializeComponent();
}
}
public partial class MainWindow : Window
{
private readonly IEngine engine;
public MainWindow()
{
// You configure the rendering mode here.
engine = EngineFactory.Create(RenderingMode.HardwareAccelerated);
IBrowser browser = engine.CreateBrowser();
InitializeComponent();
browserView.InitializeFrom(browser);
browser.Navigation.LoadUrl("https://teamdev.com");
}
private void Window_Closed(object sender, EventArgs e)
{
engine?.Dispose();
}
}
Read more about the rendering modes, their performance, and choosing between
them in the BrowserView
guide.
WinForms
In WinForms, CefSharp always uses a heavyweight rendering, the same as
in Wpf.Hwnd
.
In DotNetBrowser, the WinForms BrowserView
control will use the rendering mode
you configured when creating the IEngine
.
The rest is similar:
using CefSharp.WinForms;
...
public partial class BrowserForm : Form
{
private readonly ChromiumWebBrowser browser;
public BrowserForm()
{
InitializeComponent();
browser = new ChromiumWebBrowser("https://teamdev.com");
Controls.Add(browser);
}
}
using DotNetBrowser.WinForms;
...
public partial class BrowserForm : Form
{
private readonly IEngine engine;
public BrowserForm()
{
// You configure the rendering mode here.
engine = EngineFactory.Create(RenderingMode.HardwareAccelerated);
IBrowser browser = engine.CreateBrowser();
InitializeComponent();
BrowserView browserView = new BrowserView();
Controls.Add(browserView);
FormClosed += Form1_FormClosed;
browserView.InitializeFrom(browser);
browser.Navigation.LoadUrl("https://teamdev.com");
}
private void Form1_FormClosed(object sender, FormClosedEventArgs e)
{
engine?.Dispose();
}
}
Headless mode
CefSharp provides a special OffScreen
implementation of ChromiumWebBrowser
for headless use cases, where the browser is not shown in the UI.
In DotNetBrowser, every instance of IBrowser
is a fully-functional browser
that works without a UI.
using CefSharp.OffScreen;
...
public static class Program
{
public static int Main(string[] args)
{
var settings = new CefSettings();
Cef.Initialize(settings);
var browser = new ChromiumWebBrowser("https://www.google.com/");
...
// Just wait to keep the process running.
Console.ReadKey();
Cef.Shutdown();
return 0;
}
}
using DotNetBrowser.Browser;
using DotNetBrowser.Engine;
...
public static class Program
{
public static int Main(string[] args)
{
using (IEngine engine =
EngineFactory.Create(RenderingMode.HardwareAccelerated))
{
IBrowser browser = engine.CreateBrowser();
browser.Navigation
.LoadUrl("https://www.google.com/").Wait();
...
// Just wait to keep the process running.
Console.ReadKey();
return 0;
}
}
}
Disposing the browser
In both CefSharp and DotNetBrowser, you must close the Chromium engine and browser instances to prevent resource leaks. Closing the engine will automatically close all browser instances created by it:
// You must dispose the browser only in the main thread.
cefBrowser.Dispose();
// You may dispose the browser in any thread.
browser.Dispose();
CefSharp doesn’t provide a universal way to detect when the browser is closed.
In DotNetBrowser, you can register the Disposed
event handler, for both
browser and the engine. This event is emitted when the engine or browser are
closed, regardless of how and why they got closed.
engine.Disposed += (sender, args) =>
{
Console.WriteLine("The engine was closed!");
};
browser.Disposed += (sender, args) =>
{
Console.WriteLine("The browser was closed!");
};
Threading
In CefSharp, it’s important to always be aware of which thread you’re calling a method from. Many methods have specific thread requirements, and the documentation often includes statements like the following:
This method must be called on the CEF XYZ thread.
DotNetBrowser doesn’t impose any threading limitations. You’re allowed to use the API of the library from any thread.
Browser isolation
Data and network isolation
In CefSharp, you can isolate the browsers from each other by putting them in
different RequestContext
’s. The browsers within the same request context share
everything: preferences, cookies, cache, service workers. Respectively, the
browsers in the different request contexts are isolated.
In DotNetBrowser, the alternative for a request context is a guide-profile. The browsers created within the same profile share preferences, networking layer, cache, cookies, storage, and other things. To isolate the browsers from each other, create them in different profiles:
var publicContext = RequestContext.Configure()
.WithCachePath("<path to a public cache location>")
.Create();
var publicBrowser = new ChromiumWebBrowser("https://teamdev.com");
publicBrowser.RequestContext = publicContext;
var secureContext = RequestContext.Configure()
.WithCachePath("<path to a secure cache location>")
.Create();
var secureBrowser = new ChromiumWebBrowser("https://internal.system");
secureBrowser.RequestContext = secureContext;
var publicProfile = engine.Profiles.Default;
var publicBrowser = defaultProfile.CreateBrowser();
publicBrowser.Navigation.LoadUrl("https://teamdev.com");
var secureProfile = engine.Profiles.Create("secure-profile");
var secureBrowser = secureProfile.CreateBrowser();
secureBrowser.Navigation.LoadUrl("https://internal.system");
Runtime isolation
CefSharp runs a Chromium engine inside the .NET process. The Chromium engine is a singleton, and can be created only once per process lifetime. If the engine crashes, not just the browser instances, but the whole application goes down.
DotNetBrowser runs Chromium engines in separate processes, which keeps the .NET process unaffected when the engine crashes. When such a crash occurs, the .NET process will receive a notification:
engine.Disposed += (s, e) =>
{
if (e.ExitCode != 0)
{
// Engine has crashed.
}
};
When the engine crashes, its IBrowser
instances are also immediately closed.
By creating profiles and browsers within different IEngine
’s, you can isolate
them from crashes in each other’s engines.
Please note that creating and operating extra
IEngine
instances is resource-intensive and is rarely required.
// Start the Chromium main process for the public browser.
var publicEngine = EngineFactory.Create(RenderingMode.HardwareAccelerated);
var publicProfile = publicEngine.Profiles.Default;
var publicBrowser = defaultProfile.CreateBrowser();
publicBrowser.Navigation.LoadUrl("https://teamdev.com");
// Start the Chromium main process for the secure browser.
var secureEngine = EngineFactory.Create(RenderingMode.HardwareAccelerated);
var secureProfile = secureEngine.Profiles.Create("secure-profile");
var secureBrowser = secureProfile.CreateBrowser();
secureBrowser.Navigation.LoadUrl("https://internal.system");
Navigation methods
Most of the navigation methods in CefSharp have a one-to-one counterpart in DotNetBrowser:
ChromiumWebBrowser chromiumBrowser = new ChromiumWebBrowser();
chromiumBrowser.LoadUrl("https://teamdev.com");
IBrowser browser = chromiumBrowser.GetBrowser();
browser.GoBack();
browser.GoForward();
browser.Reload(true);
browser.StopLoad();
bool canGoBack = browser.CanGoBack;
bool canGoForward = browser.CanGoForward;
INavigation navigation = browser.Navigation;
navigation.LoadUrl("https://teamdev.com");
navigation.GoBack();
navigation.GoForward();
navigation.Reload();
navigation.ReloadIgnoringCache();
navigation.Stop();
bool canGoBack = navigation.CanGoBack();
bool canGoForward = navigation.CanGoForward();
Navigation events
Both CefSharp and DotNetBrowser provide you with means to track
the navigation status. Replace LoadingStateChanged
and LoadError
events with the combination of DotNetBrowser’s NavigationStarted
,
NavigationStopped
, and NavigationFinished
:
browser.LoadingStateChanged += (sender, args) =>
{
if (args.IsLoading)
{
Console.WriteLine("Navigation started.");
}
else
{
Console.WriteLine("Navigation completed.");
}
};
browser.LoadError += (sender, args) =>
{
if (args.ErrorCode == CefErrorCode.Aborted)
{
Console.WriteLine("Navigation aborted");
}
}
navigation.NavigationStarted += (s, e) =>
{
Console.WriteLine("Navigation started.");
};
navigation.NavigationStopped += (s, e) =>
{
Console.WriteLine("Navigation stopped.");
};
navigation.NavigationFinished += (sender, args) =>
{
if (args.ErrorCode == NetError.Aborted)
{
Console.WriteLine("Navigation aborted");
}
};
Replace FrameLoadEnd
with FrameDocumentLoadFinished
to determine when the
JavaScript context and DOM tree is ready in a frame:
browser.FrameLoadEnd += (sender, args) =>
{
if (args.Frame.IsMain)
{
Console.WriteLine("DOM and V8 context are ready in the main frame.");
}
else
{
Console.WriteLine("DOM and V8 context are in an iframe.");
}
};
navigation.FrameDocumentLoadFinished += (s, args) =>
{
if (args.frame.IsMain)
{
Console.WriteLine("DOM and V8 context are ready in the main frame.");
}
else
{
Console.WriteLine("DOM and V8 context are in an iframe.");
}
};
There are 10 granular navigation events in DotNetBrowser. Check the complete list.
Loading with POST data
In CefSharp, you can’t directly load a URL with POST parameters. To achieve that, you need to register a global request handler, cherry-pick the request you want to modify, and manually add the POST data.
In DotNetBrowser, you can directly load a URL with any POST data:
class MyRequestHandler : RequestHandler
{
protected override IResourceRequestHandler GetResourceRequestHandler(...)
{
if (request.Url == "https://my.post.endpoint")
{
return new MyResourceRequestHandler();
}
return null;
}
}
class MyResourceRequestHandler : ResourceRequestHandler
{
protected override CefReturnValue OnBeforeResourceLoad(...)
{
var postData = new PostData();
postData.AddData("username=test&password=1234");
request.Method = "POST";
request.PostData = postData;
request.SetHeaderByName(
"Content-Type", "application/x-www-form-urlencoded", true);
return CefReturnValue.Continue;
}
}
browser = new ChromiumWebBrowser("https://my.post.endpoint");
browser.RequestHandler = new CustomRequestHandler();
// Create an array with post data parameters
KeyValuePair<string, string>[] formData =
{
new KeyValuePair<string, string>("username", "test"),
new KeyValuePair<string, string>("password", "1234")
};
LoadUrlParameters request = new LoadUrlParameters("https://my.post.endpoint")
{
// DotNetBrowser will automatically derive the content type
// from the data type.
UploadData = new FormData(formData)
};
// Navigate with the custom request.
browser.Navigation.LoadUrl(request);
DotNetBrowser automatically fills in the Content-Type
and Content-Length
headers for POST requests. For multipart uploads, it also adds the form boundary
and sets each part’s Content-Disposition
and Content-Type
headers.
You can read more about making POST requests in the guide on the navigation with POST data.
Loading HTML content
The easiest way to load an HTML string in both CefSharp and DotNetBrowser is to
load it as a data:
URL:
var html = "<html>Html Encoded in URL!</html>";
var encodedHtml = Convert.ToBase64String(Encoding.UTF8.GetBytes(html));
browser.Load("data:text/html;base64," + encodedHtml);
var html = "<html>Html Encoded in URL!</html>";
var encodedHtml = Convert.ToBase64String(Encoding.UTF8.GetBytes(html));
browser.Navigation.LoadUrl("data:text/html;base64," + encodedHtml);
This method is limited by the maximum URL size of roughly ~2 MB. If you’re using
CefSharp’s ResourceHandler
to load more content, replace it with
a custom scheme request interceptor.
JavaScript
When to start executing JavaScript
To run JavaScript at the earliest possible moment, you need to know when Chromium has finished initializing the V8 JavaScript context.
CefSharp provides the OnContextCreated
event that is called when
the JavaScript context has just been created in the frame. At this moment,
no other scripts in the frame ran yet. Replace it with DotNetBrowser’s
InjectJsHandler
that has the same semantics:
class RenderProcessMessageHandler : IRenderProcessMessageHandler
{
void OnContextCreated(IWebBrowser browserControl,
IBrowser browser, IFrame frame)
{
frame.ExecuteJavaScriptAsync("...");
}
}
browser.RenderProcessMessageHandler = new RenderProcessMessageHandler();
browser.InjectJsHandler = new Handler<InjectJsParameters>(args =>
{
args.Frame.ExecuteJavaScript<IJsObject>("...");
});
Calling JavaScript from .NET
Both libraries provide similar capabilities when it comes to JavaScript, with the difference in type conversion and injecting .NET objects into JavaScript.
To execute a script, replace EvaluateScriptAsync
call
with ExecuteJavaScript
:
JavascriptResponse response = await frame.EvaluateScriptAsync("'Hello'");
string response = await frame.ExecuteJavaScript<string>("'Hello'");
While the calls look alike, the results you will be getting are different. Both CefSharp and DotNetBrowser will attempt to convert JavaScript types to their C# counterparts, but they do it differently.
CefSharp can return primitive types, simple non-cyclic JavaScript objects, and
arrays of these types. It can’t return the DOM elements or the window
objects.
DotNetBrowser returns primitive types and JavaScript **objects of any complexity **, including objects with cyclic references — the library uses the V8 objects directly, without serializing and copying them under the hood.
JavascriptResponse numberResponse = await frame.EvaluateScriptAsync("123");
int number = (int) numberResponse.Result;
JavascriptResponse booleanResponse = await frame.EvaluateScriptAsync("true");
bool boolean = (bool) booleanResponse.Result;
JavascriptResponse strResponse = await frame.EvaluateScriptAsync("'Hello'");
string str = (string) strResponse.Result;
JavascriptResponse objResponse =
await frame.EvaluateScriptAsync("({'foo': 'bar'})");
dynamic obj = objResponse.Result;
var foo = obj.foo;
// You can't do this:
JavascriptResponse windowResponse = await frame.EvaluateScriptAsync("window");
object window = strResponse.Result; // Null.
// DotNetBrowser directly converts primitive types, just like CefSharp:
double number = await frame.ExecuteJavaScript<double>("123");
bool boolean = await frame.ExecuteJavaScript<bool>("true");
string str = await frame.ExecuteJavaScript<string>("'Hello'");
IJsObject obj =
await frame.ExecuteJavaScript<IJsObject>("{'foo': 'bar'}");
var foo = obj.Properties["foo"];
// This works in DotNetBrowser.
IJsObject window = await frame.ExecuteJavaScript<IJsObject>("window");
// When possible, DotNetBrowser will select a more specific type:
IElement body = await frame.ExecuteJavaScript<IElement>("document.body");
Read more in the guide about calling JavaScript from .NET.
Calling .NET from JavaScript
In both solutions, calling the .NET code from JavaScript involves injecting a .NET object into the JavaScript world.
In CefSharp, that is a two-step process where you need to put the .NET object
into the JavascriptObjectRepository
on the .NET side, and then
asynchronously “fetch” it on the JavaScript side.
In DotNetBrowser, the approach is simpler: you assign an arbitrary .NET object to an arbitrary JavaScript property.
In C# code:
// Register a .NET object in the registry:
browser.JavascriptObjectRepository.ResolveObject += (sender, e) =>
{
var repo = e.ObjectRepository;
if (e.ObjectName == "myObject")
{
repo.Register("myObject", new MyObject(), null);
}
};
// Assign the .NET object to a property of any JavaScript object.
IJsObject window = frame.ExecuteJavaScript<IJsObject>("window").Result;
window.Properties["myObject"] = new MyObject();
In JavaScript code:
// Fetch the .NET object once:
await CefSharp.BindObjectAsync("myObject");
// Use the injected .NET object.
myObject.add(40, 2).then((sum) => console.log("Sum is: " + sum));
// You can use the JavaScript object right away:
const sum = myObject.add(40, 2);
console.log("Sum is: " + sum);
Read more about calling .NET from JavaScript in DotNetBrowser.
Intercepting traffic
Both CefSharp and DotNetBrowser allow you to intercept traffic and substitute
server responses in both standard and custom://
schemes:
public class MySchemeHandlerFactory : ISchemeHandlerFactory
{
IResourceHandler Create(IBrowser browser, IFrame frame,
string schemeName, IRequest request)
{
var uri = new Uri(request.Url);
var fileName = uri.AbsolutePath;
var responseContent = ReadMyCustomResponse(uri);
return ResourceHandler.FromString(responseContent, ...);
return null;
}
}
settings.RegisterScheme(new CefCustomScheme
{
// Corresponds to custom-sceme://
SchemeName = "custom-scheme",
// You must register a handler for the pair of scheme & host.
DomainName = "my-app.com",
SchemeHandlerFactory = new MySchemeHandlerFactory()
});
Cef.Initialize(settings);
var handler =
new Handler<InterceptRequestParameters, InterceptRequestResponse>(p =>
{
var url = p.UrlRequest.Url;
if (GetDomain(url) == "my-app.com")
{
var opts = new UrlRequestJobOptions
{
HttpStatusCode = HttpStatusCode.OK,
Headers = new List<HttpHeader>
{
new HttpHeader("Content-Type", "text/html", "charset=utf-8")
}
};
var job = p.Network.CreateUrlRequestJob(p.UrlRequest, opts);
Task.Run(() =>
{
var responseContent = ReadMyCustomResponse(url);
job.Write(Encoding.UTF8.GetBytes(responseContent));
job.Complete();
});
// Return a job that will populate the response data.
return InterceptRequestResponse.Intercept(job);
}
else
{
// Let the request through.
return InterceptRequestResponse.Proceed();
}
});
var opts = new EngineOptions.Builder
{
// Register a request interceptor for the entire scheme.
Schemes =
{
{ Scheme.Create("custom-scheme"), handler }
}
}.Build();
var engine = EngineFactory.Create(opts);
DotNetBrowser doesn’t provide alternatives to CefSharp’s convenience methods
like ResourceHandler.FromStream
or ResourceHandler.FromFilePath
.
Request handler
CefSharp provides the IRequestHandler
that allows you to modify outgoing
requests, handle authentication, and certain events from the render process. In
DotNetBrowser, the same functionality is spread across multiple individual event
handlers.
DotNetBrowser equivalents to IRequestHandler
methods:
Method in IRequestHandler | Equivalent in DotNetBrowser |
---|---|
OnSelectClientCertificate | SelectCertificateHandler |
GetAuthCredentials | AuthenticateHandler |
OnCertificateError | VerifyCertificateHandler |
OnRenderProcessTerminated | RenderProcessTerminated |
OnDocumentAvailableInMainFrame | FrameDocumentLoadFinished |
OnOpenUrlFromTab | no alternative available. To allow or cancel pop-up windows, use CreatePopupHandler . |
DotNetBrowser equivalents to IResourceRequestHandler
:
Method in IResourceRequestHandler | Equivalent in DotNetBrowser |
---|---|
GetResourceHandler | Use the custom scheme interceptor. |
OnResourceRedirect | RedirectResponseCodeReceived |
OnBeforeResourceLoad | SendUrlRequestHandler |
OnResourceLoadComplete | RequestCompleted |
OnResourceResponse | StartTransactionHandler |
GetCookieAccessFilter | StartTransactionHandler |
GetResourceResponseFilter for reading the response content | ResponseBytesReceived |
GetResourceResponseFilter to inject custom CSS | InjectCssHandler |
GetResourceResponseFilter for filtering incoming bytes | no alternative available |
OnProtocolExecution | no alternative available |
Cookie manager
CefSharp provides an ICookieManager
interface to create, read, update, and
delete cookies in the storage. There is one global cookie manager shared across
all browsers, and each RequestContext
has its own cookie manager.
DotNetBrowser provides a similar entity called ICookieStore
. All cookie stores
are bound to their respective IProfile
, with no global store available:
// The cookie manager is created in an async fasion.
// Use IBrowserProcessHandler.OnContextInitialized to know
// when it's ready to use.
var cookieManager = Cef.GetGlobalCookieManager();
// Create a cookie.
var success = cookieManager.SetCookie("google.com", new Cookie
{
Name = "name",
Value = "value",
Expires = expirationTime,
Path = "/"
});
// Delete a cookie.
cookieManager.DeleteCookies("https://google.com", "cookie-name");
// Persist cookie changes immediately.
cookieManager.FlushStore();
// Iterate over all existing cookies.
cookieManager.VisitAllCookies(new CookieVisitor());
// Iterate over all cookies for a give URL.
bool withHttpOnly = false;
cookieManager.VisitUrlCookies(
"httos://google.com", withHttpOnly, new CookieVisitor());
// No initialization required, you can use the cookie store right away.
var cookieStore = profile.CookieStore;
// Create a cookie.
Cookie cookie = new Cookie.Builder("google.com")
{
Name = "name",
Value = "value",
ExpirationTime = expirationTime,
Path = "/"
}.Build();
await engine.Profiles.Default.CookieStore.SetCookie(cookie);
// Delete a cookie.
await cookieStore.CookieStore.Delete(cookie);
// Persist cookie changes immediately.
cookieStore.Flush();
// Read all cookies.
IEnumerable<Cookie> allCookies =
await cookieStore.CookieStore.GetAllCookies();
// Read all cookies for a give URL.
IEnumerable<Cookie> urlCookies =
await cookieStore.CookieStore.GetAllCookies("https://google.com");
Proxy
CefSharp allows you to configure proxy in two ways:
- by using special Chromium switches when initializing the engine;
- by changing the proxy in
IRequestContext
at runtime.
In DotNetBrowser, the preferred way is to configure the proxy at runtime
using IProfile
instances, which you can do before creating any IBrowser
instances.
// Specify global proxy settings for all browsers.
var settings = new CefSettings();
// Inherit system proxy settings.
settings.CefCommandLineArgs.Add("no-proxy-server");
// Use Web Proxy Auto-Disovery.
settings.CefCommandLineArgs.Add("proxy-auto-detect");
// Manually configure the proxy.
settings.CefCommandLineArgs.Add(
"proxy-server=http=proxy.com:8080;https=proxy.com:8081");
// Use the PAC file.
settings.CefCommandLineArgs.Add("proxy-pac-url=URL");
Cef.Initialize(settings);
// Alternatively, configure the proxy for a specific RequestContext:
var requestContext = RequestContext
.Configure()
.WithProxyServer("proxy.com", 8080)
.Create();
IProxy proxy = profile.Proxy;
// Inherit system proxy settings.
proxy.Settings = new SystemProxySettings();
// Don't use any proxy servers.
proxy.Settings = new DirectProxySettings();
// Use Web Proxy Auto-Disovery.
proxy.Settings = new AutoDetectProxySettings();
// Manually configure the proxy.
string proxyRules = "http=proxy.com:8080;https=proxy.com:8081";
proxy.Settings = new CustomProxySettings(proxyRules);
// Use the PAC file.
proxy.Settings = new PacProxySettings("<pac-file-url>");
To authenticate the proxy, replace the
CefSharp’s IRequestHandler.GetAuthCredentials
with the AuthenticateHandler
:
class CustomRequestHandler : CefSharp.Handler.RequestHandler
{
override bool GetAuthCredentials(...)
{
if (isProxy)
{
using (callback)
{
callback.Continue(username: "user", password: "pass");
}
return true;
}
// Cancel the authentication request.
return false;
}
}
browser.RequestHandler = new CustomRequestHandler();
network.AuthenticateHandler =
new Handler<AuthenticateParameters, AuthenticateResponse>(p =>
{
if (p.IsProxy)
{
return AuthenticateResponse.Continue("user", "pass"));
}
return AuthenticateResponse.Cancel();
};
Popups
In CefSharp, the pop-up browsers are controlled using the ILifeSpanHandler
. By
using either WPF or WinForms implementation of this interface, you can show the
newly created browser in a new window. For example, here’s how it looks in
WinForms:
browser.LifeSpanHandler = CefSharp.WinForms.Handler.LifeSpanHandler
.Create()
.OnBeforePopupCreated((...) => {
if (...)
{
return PopupCreation.Continue;
}
else
{
return PopupCreation.Cancel;
}
})
.OnPopupCreated((ctrl, targetUrl) =>
{
parent.Controls.Add(ctrl);
})
.OnPopupDestroyed((ctrl, popupBrowser) =>
{
if (!ctrl.IsDisposed && ctrl.IsHandleCreated)
{
parent.Controls.Remove(ctrl);
}
}).Build();
In DotNetBrowser, you will need to replace it with two handlers:
CreatePopupHandler
to enable/disable the creation of a pop-up.OpenPopupHandler
to show the pop-up, if needed.
In the OpenPopupHandler
, you receive the newly created instance of IBrowser
and you will be able to use it in a headless mode, or display in the UI
using BrowserView
. By default, if the browser is in BrowserView
, it opens
the pop-up in a new window; otherwise, it suppresses the pop-up:
class MyOpenPopupHandler : IHandler<OpenPopupParameters>
{
private readonly Control parent;
public MyOpenPopupHandler(Control parent)
{
this.parent = parent;
}
public void Handle(OpenPopupParameters parameters)
{
Action showPopupAction = () =>
{
ShowPopup(parameters.PopupBrowser,
parameters.Rectangle);
};
parent.BeginInvoke(showPopupAction);
}
private void ShowPopup(IBrowser popupBrowser, Rectangle rectangle)
{
BrowserView browserView = new BrowserView
{
Dock = DockStyle.Fill
};
browserView.InitializeFrom(popupBrowser);
// Add the browser view to the parent and show it.
}
}
browser.CreatePopupHandler =
new Handler<CreatePopupParameters, CreatePopupResponse>(p =>
{
if (...)
{
return CreatePopupResponse.Create();
}
else
{
return CreatePopupResponse.Suppress();
}
});
// Set this handler if you don't want the DotNetBrowser's default behavior:
// to show the pop-up in a new window.
browser.OpenPopupHandler = new MyOpenPopupHandler(parent);
JavaScript Dialogs
CefSharp provides the IJsDialogHandler
that allows you to handle
the JavaScript dialogs. In DotNetBrowser, you can replace it
with individual handlers:
class MyDialogHandler : IJsDialogHandler
{
// Handle alert, prompt, and confirm dialogs in this method.
bool OnJSDialog(IWebBrowser chromiumWebBrowser, ...)
{
...
}
// Handle onBeforeUnload dialog in this method.
bool OnBeforeUnloadDialog(IWebBrowser chromiumWebBrowser, ...)
{
...
}
// The following methods have no alternative in DotNetBrowser, because
// you completely control the state of the dialog in the .NET code.
void OnResetDialogState(IWebBrowser chromiumWebBrowser, IBrowser browser)
{
...
}
void OnDialogClosed(IWebBrowser chromiumWebBrowser, IBrowser browser)
{
...
}
}
browser.JsDialogHandler = new MyDialogHandler();
var dialogs = browser.JsDialogs;
dialogs.AlertHandler = new Handler<AlertParameters>(p => { });
dialogs.ConfirmHandler =
new Handler<ConfirmParameters, ConfirmResponse>(p =>
{
...
return ConfirmResponse.Ok();
});
dialogs.PromptHandler =
new Handler<PromptParameters, PromptResponse>(p =>
{
...
return PromptResponse.SubmitText("some response");
});
dialogs.BeforeUnloadHandler =
new Handler<BeforeUnloadParameters, BeforeUnloadResponse>(p =>
{
...
return BeforeUnloadResponse.Leave();
});
If you don’t set up a handler, DotNetBrowser manages the dialogs automatically.
Inside a BrowserView
, it shows the default dialog implementation using
the application’s UI library. Otherwise, it skips the dialogs as if
the user pressed “Cancel”.
Downloads
CefSharp provides the IDownloadHandler
for controlling the downloading
process. In DotNetBrowser, the direct replacement
is StartDownloadHandler
:
class MyDownloadHandler : IDownloadHandler
{
bool OnBeforeDownload(IWebBrowser chromiumWebBrowser, IBrowser browser,
DownloadItem downloadItem,
IBeforeDownloadCallback callback)
{
if (downloadItem.IsValid)
{
string downloadPath =
Path.GetFullPath(downloadItem.SuggestedFileName);
if (!callback.IsDisposed)
{
using (callback)
{
callback.Continue(
downloadPath: downloadPath,
// Show the default save dialog.
showDialog: true
);
}
}
return true;
}
// Let CefSharp handle the download.
// In Alloy, the download is cancelled by default.
return false;
}
void OnDownloadUpdated(IWebBrowser chromiumWebBrowser, IBrowser browser,
DownloadItem downloadItem,
IDownloadItemCallback callback)
{
if (downloadItem.IsValid)
{
if (downloadItem.IsComplete)
{
Console.WriteLine("Download completed");
}
}
}
}
browser.DownloadHandler = new MyDownloadHandler();
browser.StartDownloadHandler =
new Handler<StartDownloadParameters, StartDownloadResponse>(p =>
{
var fileName = p.Download.Info.SuggestedFileName;
var targetPath = Path.GetFullPath(fileName);
p.Download.Finished += (sender, args) =>
{
Console.WriteLine("Download completed");
};
// Return StartDownloadResponse.Cancel() to cancel the download.
return StartDownloadResponse.DownloadTo(targetPath);
});
If you don’t configure this handler, DotNetBrowser handles the downloads
automatically. Inside a BrowserView
, it presents the “Save As” dialog using
the application’s UI library. Outside of that context, it cancels
the download.
Visit the guide on Downloads to find more details.
Screenshots
In CefSharp, you can capture a screenshot only using the DevTools protocol. DotNetBrowser provides a method for that — you don’t need to use DevTools or expose the remote debugging port:
using (var devToolsClient = chromiumWebBrowser.GetDevToolsClient())
{
var result = await devToolsClient.Page.CaptureScreenshotAsync();
byte[] pixels = result.Data;
}
// Get the raw pixels of the current viewport.
// No DevTools or window required.
DotNetBrowser.Ui.Bitmap image = browser.TakeImage();
// Save the image to the file.
Bitmap bitmap = ToBitmap(image);
bitmap.Save("screenshot.png", ImageFormat.Png);
Check out the advanced tutorial on taking screenshots in DotNetBrowser.
DevTools
In both CefSharp and DotNetBrowser, you can configure the remote debugging port and open the DevTools for each browser:
var settings = new CefSettings();
settings.RemoteDebuggingPort = 9222;
settings.CefCommandLineArgs.Add("remote-allow-origins=http://localhost:9222");
Cef.Initialize(settings);
...
// Open the dev tools window.
browser.ShowDevTools();
// Close it.
browser.HideDevTools();
IEngine engine = EngineFactory.Create(new EngineOptions.Builder
{
ChromiumSwitches = { "--remote-allow-origins=http://localhost:9222" },
RemoteDebuggingPort = 9222
}.Build());
...
// Open the dev tools window.
browser.DevTools.Show();
// Close it.
browser.DevTools.Hide();
// Or open the dev tools in another browser by URL.
string url = browser.DevTools.RemoteDebuggingUrl;
DotNetBrowser doesn’t provide an alternative to CefSharp'
s browser.GetDevToolsClient()
.
User Agent
In CefSharp, you can configure the user agent in three ways:
- beforehand, when initializing CEF;
- at runtime, using the DevTools protocol;
- at runtime, by overriding the
User-Agent
header of a request.
In DotNetBrowser, you can set the default user agent when creating
the IEngine
:
IEngine engine = EngineFactory.Create(new EngineOptions.Builder
{
UserAgent = "<user-agent>"
}.Build());
At runtime, you can override this value for an individual browser:
browser.UserAgent = "<user-agent>";
Or for an individual request
using StartTransactionHandler
:
network.StartTransactionHandler =
new Handler<StartTransactionParameters, StartTransactionResponse>(p =>
{
var newHeaders = p.headers.Cast<HttpHeader>().ToList();
newHeaders.Add(
new HttpHeader("User-Agent", "Mozilla/5.0 ..."));
return StartTransactionResponse.OverrideHeaders(newHttpHeaders);
});
Alternatively, you can specify the User Agent Client Hints.
Conclusion
If you’ve used CefSharp, you’ll find that DotNetBrowser works in similar ways. Most of the features are available, with a few changes in how they’re used.
In this guide, we went through migrating the browser lifecycle management, navigation, pop-ups and dialogs, JavaScript, and many more.
We hope that this guide will be of great help and make the migration from CefSharp to DotNetBrowser a smooth experience.
Sending…
Sorry, the sending was interrupted
Please try again. If the issue persists, contact us at info@teamdev.com.
Your personal DotNetBrowser trial key and quick start guide will arrive in your Email Inbox in a few minutes.
